Model：YS-MWT30
30kW Faster Charging Module
introduce：
Meet the YS-MWT30, a high-power configuration within the Superior Charging Module series. Supporting voltages of up to 1000V, it’s ideal for high-traffic charging stations. YS-MWT30 enables faster charging, delivering more efficient energy to users, getting them back on the road swiftly.
Leave Your Message
We will reply you within 24 hours after you submit your information! Thank you for your call, thanks!
Output power & Input voltage curve
Output power & temperature curve
Output voltage & Output current curve
Interested in purchasing electric vehicle charging equipment for your personal or business use?
Liên hệ chúng tôi
Thank you for your interest in YUNSHAO. For more information about your business’ products, services, pricing, please fill out the form, and a YUNSHAO representative will contact you within 24 hours.
Reach us through
Tel: +86-18476803818
Email: info@yunshaoevcharger.com
ADD：No. 22, Dafu Industrial Zone, Dafu Community, Guanlan Street, Longhua District, Shenzhen City, Guangdong Province, China
Complete form to get your price quote!
Model：YS-MWT30
30kW Faster Charging Module
introduce：
Meet the YS-MWT30, a high-power configuration within the Superior Charging Module series. Supporting voltages of up to 1000V, it’s ideal for high-traffic charging stations. YS-MWT30 enables faster charging, delivering more efficient energy to users, getting them back on the road swiftly.
Leave Your Message
We will reply you within 24 hours after you submit your information! Thank you for your call, thanks!
Output power & Input voltage curve
Output power & temperature curve
Output voltage & Output current curve
Product parameters
| Specification | Model | YS-MWT30 |
| AC Input | Input Voltage | Rated voltage 380VAC, three phase no center line，operating range 285-475VAC |
| Input Frequency | 50/60±5Hz | |
| Input Power Factor | ≥0.99 | |
| Input Overvoltage Protection | 490±5VAC | |
| Input Undervoltage Protection | 270±5VAC | |
| DC Output | Rated Output Power | 30kW |
| Output Voltage Range | 50~1000VDC | |
| Output Current Range | 0.5~120A | |
| Output Constant Power Range | When output voltage is 250-1000VDC, constant 30kW will output. | |
| Peak Efficiency | ≥96% | |
| Soft Start Time | 3-8S | |
| Short Circuit Protection | Self-rollback protection | |
| Voltage Regulation Accuracy | ≤±0.5 | |
| THD | ≤5% | |
| Current Regulation Accuracy | ≤±1% | |
| Current Sharing Imbalance | ≤±5% | |
| Operating Environment | Working Temperature | -40℃- +75℃ |
| Relative Humidity | ≤95% no condensation | |
| Altitude | ≤2000m, derating above 2000m | |
| Product Features | Cooling Method | Fan cooling |
| Standby Power Consumption | ＜12W | |
| Communication Protocol | CAN | |
| Address Setting | Digital screen display, keys operation | |
| Module Dimension (without Handle) | 437.5*300*84mm(L*W*H) | |
| Weight | ≤15kg | |
| MTBF | 500000 hours |
